SJ Series Single Screw Extruder Two Stage Pelletizer with 300kg per hour Capacity and Siemens PLC Control for Efficient Plastic Recycling
SJ Series Single Screw Extruder Two Stage Pelletizer with 300kg per hour Capacity and Siemens PLC Control for Efficient Plastic Recycling
Basic Properties
Country Of Origin
China
Brand Name
PULIER/PR
Certificate
CE
PRODUCT MODEL
SJ100/120
Trading Properties
MOQ
1set
Unit Price
USD50000 per set-USD200,000 per set
Payment Method
L/C,T/T
Product Summary
SJ Series Single Screw Extruder 300kg/Hr Two Stage Recycling Machine For Pelletizing PR-PUlier, a leader in plastics recycling for 18 years, presents the SJ type Single-Screw Extruder Two-Stage Pelletizer. This advanced plastic recycling machine revolutionizes the processing of laminated and ...
Product Details
Highlight:
Sj Series Single Screw Extruder
,Single Screw Extruder 300kg/Hr
,Two Stage Recycling Machine For Pelletizing
Product Name:
Single Screw Extruder
Processing Material:
Squeezed PP PE Films And Bags, ABS, Rigid HDPE,PP, PA /PA66 Etc
Cutter Compactor:
With
Pelletizing:
Horizontal Watering Pelletizing
Capacity:
300kg Per Hour
Control:
Siemens PLC
Motor:
WEG Or Wannan
Screw And Barrel Material:
38CrMoA1A，nitrogen Treatment
Product Description
SJ Series Single Screw Extruder 300kg/Hr Two Stage Recycling Machine For Pelletizing
PR-PUlier, a leader in plastics recycling for 18 years, presents the SJ type Single-Screw Extruder Two-Stage Pelletizer. This advanced plastic recycling machine revolutionizes the processing of laminated and contaminated PP (polypropylene), PE (polyethylene), PS, ABS, PC, and PA6/PA66 materials, delivering exceptional efficiency, reliability, and pellet quality.
Our two-stage granulation process begins with melting and homogenizing plastic materials, effectively processing even heavily contaminated and laminated plastics through vacuum degassing and laser/normal filtration. The second stage converts the melted plastic into high-quality reusable pellets.
Key Advantages
- High Efficiency: Two-stage process maximizes output while minimizing energy consumption
- Material Versatility: Processes various PP and PE materials, including heavily laminated or contaminated plastics
- Robust Construction: High-quality components ensure long-term reliability with minimal maintenance
- Intuitive Operation: Siemens PLC touch screen interface with easy-to-follow instructions
- Consistent Quality: Advanced design produces uniform pellet size meeting industry standards
General Information
The SJ pelletizing machine specializes in rigid plastics recycling including crushed or regrind PE, PP, PS, ABS, PC, and PA6 materials from household appliances, HDPE drums, bottles, and containers. It also processes washed and squeezed dry PE and PP films and soft plastics.
Applications
- Crushed or regrind PE, PP, PS, ABS, PC, PA6
- Squeezed washed PP and PE films
Technical Specifications
| Model | SJ100/120 | SJ130/140 | SJ150/160 | SJ160/180 | SJ180/200 |
|---|---|---|---|---|---|
| Raw Material | Squeezed PP, PE films, HDPE bottle flakes, rigid ABS, PS, PC etc | ||||
| Capacity (Kg/Hour) | 250-350 | 500 | 600-600 | 700-800 | 800-1000 |
| Main Motor Power (kW) | 90/37 | 132/45 | 160/55 | 185-200/55 | 250-315/75 |
Advanced Features
- Dual Filtration System: Two-stage filtering with 60 mesh first stage and 80-100 mesh second stage ensures superior pellet quality
- Enhanced Vacuum Degassing: Water-ring vacuum pump with water cylinder filtration for effective gas extraction
- Material-Specific Screw Design: Customized screw configurations optimized for different plastic materials
- Premium Heating Elements: High-reliability barrel heaters with extended service life
- Flexible Pelletizing Options: Water-ring pelletizing for PP/PE films, strand pelletizing for PP/PE/PC/ABS/PA, or universal underwater pelletizing
- Premium Components: WEG UL-certified, ABB, or Siemens motors; Schneider or Siemens electrical parts; OMRON temperature control
- Safety-Focused Design: Comprehensive safety features and strict quality control for plant operation
With 18+ years of expertise and exports to over 80 countries worldwide, PR-PUlier delivers proven plastic recycling solutions backed by experienced technical support.
